Siemens SIRIUS 3RW5 series User Manual

Appendix
A.2 Data tables
SIRIUS 3RW5 Modbus TCP communication module
Manual, 03/2018, A5E43676481002A/RS-AA/001
91
Register
Byte
Data format
[Obj. No.]
Parameters
Range of values
[encoding]
Increment
3RW
Address
high / low
52
1)
[D*]
55
2)
[D*]
SIRIUS 3RW55 soft starter,
High Feature, 570 A,
3-phase controlled, motor
overload protection, torque
control
114 … 987 A
[11 400 … 98 700]
0.01 A - [11 400]
SIRIUS 3RW55 soft starter,
High Feature, 630 A,
3-phase controlled, motor
overload protection, torque
control
126 … 1 091 A
[12 600 … 109 100]
0.01 A - [12 600]
SIRIUS 3RW55 soft starter,
High Feature, 720 A,
3-phase controlled, motor
overload protection, torque
control
144 … 1 247 A
[14 400 … 124 700]
0.01 A - [14 400]
SIRIUS 3RW55 soft starter,
High Feature, 840 A,
3-phase controlled, motor
overload protection, torque
control
168 … 1 454 A
[16 800 … 145 400]
0.01 A - [16 800]
SIRIUS 3RW55 soft starter,
High Feature, 1100 A,
3-phase controlled, motor
overload protection, torque
control
220 … 1 905 A
[22 000 … 190 500]
0.01 A - [22 000]
SIRIUS 3RW55 soft starter,
High Feature, 1280 A,
3-phase controlled, motor
overload protection, torque
control
256 … 2 217 A
[25 600 … 221 700]
0.01 A - [25 600]
0x9405 high Unsigned8
[2212]
Service factor 1 … 1.15
[100 … 115]
0.01 - r/w
[100]
0x9406 high Unsigned16
[113]
Rated torque 0 … 10 000 Nm
[0 … 10 000]
1 Nm - r/w
[0]
0x9407 high Unsigned16
[104]
Rated operating speed 500 … 3 600 rpm
[500 … 3 600]
1 rpm - r/w
[1500]
0x9408 high Bit4
[228]
Motor connection type
[0 ... 2]
- - r/w
[0]
[0] Automatic detection
[1] Star/delta
[2] Inside_delta
0x9409 high Bit4
[167]
Starting mode
[0 ... 6]
- r
[5]
r/w
[5]
[0] Direct
[1] Voltage ramp
[2] Torque control
[3] Motor heating
[5] Voltage ramp +
Current limiting
[6] Torque control +
Current limiting
