Siemens SIRIUS 3RW5 series User Manual

Appendix
A.2 Data tables
SIRIUS 3RW5 Modbus TCP communication module
94 Manual, 03/2018, A5E43676481002A/RS-AA/001
Register
Byte
Data format
[Obj. No.]
Parameters
Range of values
[encoding]
Increment
3RW
Address
high / low
52
1)
[D*]
55
2)
[D*]
0x942B high Unsigned8
[2341]
Current lower limit warning 20 … 100 %
[20 … 100]
5 % - r/w
[0]
[0] Deactivated
0x942C high Unsigned32
[2250]
Active power reference
value
0 … 2 000 000 W
[0 … 2 000 000]
1 W - r/w
[0]
0x942E high Unsigned16
[2251]
Active power upper limit
error
0 … 400 %
[0 … 400]
1 % - r/w
[0]
0x942F high Unsigned16
[2252]
Active power upper limit
warning
0 … 400 %
[0 … 400]
1 % - r/w
[0]
0x9430 high Unsigned8
[2254]
Active power lower limit
error
0 … 100 %
[0 … 100]
1 % - r/w
[0]
0x9431 high Unsigned8
[2255]
Active power lower limit
warning
0 … 100 %
[0 … 100]
1 % - r/w
[0]
0x9432 high Unsigned16
[2317]
Starting time upper limit
warning
0 … 400 %
[0 … 400]
1 % - r/w
[0]
0x9433 high Unsigned8
[2320]
Starting time lower limit
warning
0 … 100 %
[0 … 100]
1 % - r/w
[0]
0x9434 high Bit4
[2218]
Warning asymmetry limit 10 … 60 %
[2 … 12]
5 % - r/w
[0]
[0] Deactivated
0x9435 high Bit4
[21]
Asymmetry limit error 10 … 60 %
[2 … 12]
5 % - r/w
[6]
[0] Deactivated
0x9436 high Unsigned8
[2220]
Ground fault limit warning 10 … 95 %
[2 … 19]
5 % - r/w
[0]
[0] Deactivated
0x9437 high Unsigned8
[2294]
Ground fault limit error 10 … 95 %
[2 … 19]
5 % - r/w
[4]
[0] Deactivated
0x9438 high Bit4
[2242]
Emergency start
[0 ... 1]
- - r/w
[1]
[0] Disable
[1] Manually enable/
disable
0x943A high Unsigned8
[194]
Input 1-Action
[0 ... 45]
- - r/w
[16]
[0] No action
[6] Manual operation local
[7] Emergency start
[10] Creep speed
[11] Quick-stop
[12] Reset
[16] Motor CW with PS1
[17] Motor CCW with PS1
[18] Motor CW with PS2
[19] Motor CCW with PS2
[20] Motor CW with PS3
[21] Motor CCW with PS3
