Appendix
A.2 Data tables
SIRIUS 3RW5 Modbus TCP communication module
Manual, 03/2018, A5E43676481002A/RS-AA/001
95
Register
Byte
Data format
[Obj. No.]
Parameters
Range of values
[encoding]
Increment
3RW
Address
high / low
52
1)
[D*]
55
2)
[D*]
[43] Motor standstill
[44] Use alternative
stopping mode
[45] Pump cleaning mode
0x943B high Unsigned8
[195]
Input 2-Action (see Input 1-Action) - - r/w
[0]
0x943C high Unsigned8
[196]
Input 3-Action (see Input 1-Action) - - r/w
[0]
0x943D high Unsigned8
[197]
Input 4-Action (see Input 1-Action) - - r/w
[12]
0x943E high Unsigned8
[163]
Output 1-Action
[0 ... 201]
- r
[14]
r/w
[13]
[0] No action
[1] Control source
PIQ-DO-1.0 output 1
[2] Control source
PIQ-DO-1.1 output 2
[6] Control source input 1
[7] Control source input 2
[8] Control source input 3
[9] Control source input 4
[10] Start-up
[11] Operation / bypass
[12] Run-down
[13] On time motor (RUN)
[14] Control command
MOTOR ON
[16] DC braking contactor
[18] Device on
[19] Operation /
Run-down
[31] Group warning
[32] Group error
[33] Bus error
[34] Device error
[38] Ready to start for
motor ON
[41] Generator operation
[42] Pump cleaning active
[43] Alternative stopping
mode active
[44] CM - maintenance
demanded
[45] CM - error
[180] Control source PIQ-
DO 2.0 output 3
[200] Reversing
switching element - right
[201] Reversing
switching element - left
0x943F high Unsigned16
[159]
Output 1-Time 0 … 6 500 s
[0 … 65 000]
0.1 s - r/w
[0]
