SINAMICS S120 Cabinet Modules
Engineering Information
SINAMICS Engineering Manual – November 2015
Ó Siemens AG
402/528
Active Line Module +
Active Interface Module
Weight
Active Line Module +
Active Interface Module
Weight
Frame size
P
rated
at 400 V
[kW]
[kg]
Frame size
P
rated
at 690 V
[kW]
[kg]
Supply voltage 380 V to 480 V 3AC Supply voltage 500 V to 690 V 3AC
FI+FX 132 380 HI+HX 630 930
FI+FX 160 380 JI+JX 800 1360
GI+GX 235 530 JI+JX 1100 1360
GI+GX 300 530 JI+JX 1400 1360
HI+HX 380 930
HI+HX 500 930
JI+JX 630 1360
JI+JX 900 1360
Motor Modules Chassis Weight Motor Modules Chassis Weight
Frame size
P
rated
at 400 V
[kW]
[kg]
Frame size
P
rated
at 690 V
[kW]
[kg]
Supply voltage 380 V to 480 V 3AC Supply voltage 500 V to 690 V 3AC
FX 110 145 FX 75 145
FX 132 145 FX 90 145
GX 160 286 FX 110 145
GX 200 286 FX 132 145
GX 250 286 GX 160 286
HX 315 490 GX 200 286
HX 400 490 GX 250 286
HX 450 490 GX 315 286
JX 560 700 HX 400 490
JX 710 700 HX 450 490
JX 800 700 HX 560 490
JX 710 700
JX 800 700
JX 900 700
JX 1000 700
JX 1200 700
Booksize Cabinet Kits Weight
Frame size I
rated
[A] [kg]
Supply voltage 380 V to 480 V 3AC
100mm
3
1)
20.1
200mm 2*3
1)
23.3
100mm 5
1)
20.1
200mm 2*5
1)
23.3
100mm 9 20
200mm 2*9
1)
23.3
100mm 18 20
200mm 2*18
1)
24.8
100mm 30 21.9
200mm 45 27
200mm 60 27
200mm 85 33
300mm 132 41
300mm 200
1)
41
1) Production of these Booksize Cabinet Kits discontinued on 1st October 2013
Booksize Base Cabinets Weight
Frame size I
rated
[A] [kg]
Supply voltage 380 V to 480 V 3AC
800mm
170
1200mm 240
