7.2.2.11 Weights of S120 Cabinet Modules
The weights of the SINAMICS S120 Cabinet Modules are an aspect to be taken into account when configuring the
drive system. The weights of all the Cabinet Modules to be included in the final drive configuration must be calculated
and taken into account when the firmness of the floor at the site of installation is assessed.
The tables below list the cabinet weights of the SINAMICS S120 Cabinet Modules. The specified weights apply to
standard Cabinet Modules without additional options. The relevant weight of a Cabinet Module is stated in the
accompanying test certificate and on the rating plate. This weight information corresponds to the actual configuration
of the unit supplied.
The weights given below must be regarded as the minimum weights of Cabinet Modules:
Line Connection Modules Weight Line Connection Modules Weight
Frame size I
rated
[A] [kg] Frame size I
rated
[A] [kg]
Supply voltage 380 V to 480 V 3AC Supply voltage 500 V to 690 V 3AC
FL 250 210 FL 280 220
1
/ 260
2
FL
380
230
FL
380
230
1
/ 310
2
GL
600
310
1
/ 360
2
GL
600
310
1
/ 400
2
HL
770
340
1
/ 420
2
HL
770
340
JL
1000
450
JL
1000
450
1
/ 650
2
JL
1250
470
1
/ 570
2
JL
1250
470
1
/ 670
2
JL
1600
490
1
/ 650
2
JL
1600
490
1
/ 680
2
KL
2000
600
1
/ 760
2
KL
2000 for par.
600
1
/ 980
2
KL
2000 for par.
620
1
/ 820
2
KL
2500 for par.
620
1
/ 1000
2
KL
2500 for par.
620
1
/ 900
2
LL
3200 for par.
720
1
/ 1080
2
LL
3200 for par.
720
1
/ 1000
2
Basic Line Modules Weight Basic Line Modules Weight
Frame size
P
rated
at 400 V
[kW]
[kg]
Frame size
P
rated
at 690 V
[kW]
[kg]
Supply voltage 380 V to 480 V 3AC Supply voltage 500 V to 690 V 3AC
FB 200 166 FB 250 166
FB 250 166 FB 355 166
FB 400 166 FB 500 166
GB 560 320 GB 900 320
GB 560_PR
3
440 GB 900_PR
3
440
GB 560_PL
4
480 GB 900_PL
4
480
GB 710 320 GB 1100 320
GB 710_PR
3
440 GB 1100_PR
3
440
GB 710_PL
4
480 GB 1100_PL
4
480
GD 900 320 GD 1500 320
GD 900_PR
3
440 GD 1500_PR
3
440
GD 900_PL
4
480 GD 1500_PL
4
480
Smart Line Modules Weight Smart Line Modules Weight
Frame size
P
rated
at 400 V
[kW]
[kg]
Frame size
P
rated
at 690 V
[kW]
[kg]
Supply voltage 380 V to 480 V 3AC Supply voltage 500 V to 690 V 3AC
GX 250 270 GX 450 270
GX 355 270 HX 710 550
HX 500 490 JX 1000 795
JX 630 775 JX 1400 795
JX 800 775
1
With option L42 / L44
2
With option L43
3
Unit for parallel connection on a Line Connection Module on the right
4
Unit for parallel connection on a Line Connection Module on the left
