7.3.2.10 Weights of S120 Cabinet Modules
The weights of the liquid-cooled S120 Cabinet Modules are an aspect to be taken into account when configuring the
drive system. The weights of the cabinets for the relevant configuration must be calculated and checked against the
firmness of the floor at the site of installation.
The weights of liquid-cooled S120 Cabinet Modules are listed in the tables below. The weight data specified in the
tables refer to standard models without options. The relevant weight of a cabinet unit is specified on the supplied test
certificate and on the rating plate. The specified weight corresponds to the actual configuration of the supplied
cabinet.
The weight values specified below are the minimum weights of the liquid-cooled Cabinet Modules:
Basic Line Connection Modules
Standard version without options
Basic Line Connection Modules
Standard version without options
Frame size P
rated
at 400 V
[kW]
Weight
[kg]
Frame size P
rated
at 690 V
[kW]
Weight
[kg]
Line supply voltage 380 V to 480 V 3AC Line Supply voltage 500 V to 690 V 3AC
HL+FBL 360 688 GL+FBL 355 578
JL+FBL 600 838 HL+FBL 630 668
JL+GBL 830 995 JL+GBL 1100 995
JL+GBL 1370 1025
Active Line Connection Modules
Standard version without options
Active Line Connection Modules
Standard version without options
Frame size P
rated
at 400 V
[kW]
Weight
[kg]
Frame size P
rated
at 690 V
[kW]
Weight
[kg]
Line supply voltage 380 V to 480 V 3AC Line Supply voltage 500 V to 690 V 3AC
JL+JIL+JXL 630 1430 JL+JIL+JXL 1000 1520
JL+JIL+JXL 900 1470 JL+JIL+JXL 1400 1540
JL+JIL+JXL 1700 1640
Motor Modules
Standard version without options
Motor Modules
Standard version without options
Frame size P
rated
at 400 V
[kW]
Weight
[kg]
Frame size P
rated
at 690 V
[kW]
Weight
[kg]
Line supply voltage 380 V to 480 V 3AC Line Supply voltage 500 V to 690 V 3AC
HXL 315 350 HXL 450 350
HXL 400 350 HXL 560 350
HXL 450 350 HXL 710 350
JXL 560 460 HXL 800 350
JXL 710 460 JXL 800 460
JXL 800 (1330 A) 470 JXL 1000 460
JXL 800 (1405 A) 460 JXL 1200 460
JXL 1500 470
Heat Exchanger Modules
Standard version without options
Heat Exchanger Modules
Standard version without options
Frame size P
rated
at 400 V
[kW]
Weight
[kg]
Frame size P
rated
at 690 V
[kW]
Weight
[kg]
Line supply voltage 380 V to 415 V 3AC Line supply voltage 660 V to 690 V 3AC
- 32 540 - 32 540
- 48 565 - 48 565
- 72 608 - 72 608
- 110 628 - 110 628
Please note the centers of gravity when lifting or installing the cabinets. A sticker showing a precise specification of
the center of gravity is attached to all cabinets/transport units. Each cabinet or transport unit is weighed prior to
shipment. The weight specified on the control sheet enclosed with the delivery might deviate slightly from the
standard weights specified above.
Owing to the weight of the cabinets, suitable hoisting gear operated by trained personnel is also required.
