Engineering Information
SINAMICS Engineering Manual – November 2015
Ó Siemens AG
44/528
Output
power
SINAMICS
S120 ALM
at 400 V
or 690 V
[ kW ]
Frame
size
[ - ]
Rated
input current
[ A ]
Maximum
short-circuit current
[ kA ]
Minimum
short-circuit
current
[ kA ]
Min. relative
short-circuit
power
RSC
min
[ - ]
Max. relative
short-circuit
voltage
v
k max
[ % ]
SINAMICS S120 ALM + AIM / 380 V – 480 V 3AC
132 FX 210 65
1
/ 65
2
3.0 14.3 7.0
160 FX 260 65
1
/ 65
2
3.6 13.8 7.2
235 GX 380 65
1
/ 50
2
5.2 13.7 7.3
300 GX 490 65
1
/ 50
2
8.0 16.3 6.1
300 GXL 490 65
1
8.0 16.3 6.1
380 HX 605 65
1
/ 50
2
9.2 15.2 6.6
380 HXL 605 65
1
9.2 15.2 6.6
450 HX 745 84
1
8.8 11.8 8.5
500 HX 840 84
1
/ 84
3
10.4
1
/ 2.0
3
12.4
1
/ 2.4
3
8.1
1
/ ≈ 10
3
500 HXL 840 84
1
10.4 12.4 8.1
630 JX 985 84
1
/ 84
3
16.0
1
/ 2.0
3
16.2
1
/ 2.0
3
6.2
1
/ ≈ 10
3
630 JXL 985 84
1
/ 84
3
16.0
1
/ 2.0
3
16.2
1
/ 2.0
3
6.2
1
/ ≈ 10
3
800 JX 1260 170
1
21.0 16.7 6.0
900 JX 1405 170
1
/ 100
3
21.0
1
/ 3.2
3
15.0
1
/ 2.3
3
6.7
1
/ ≈ 10
3
900 JXL 1405 170
1
/ 100
3
21.0
1
/ 3.2
3
15.0
1
/ 2.3
3
6.7
1
/ ≈ 10
3
SINAMICS S120 ALM + AIM / 500 V – 690 V 3AC
630 HX 575 65
1
/ 50
2
8.4 14.6 6.8
630 HXL 575 65
1
8.4 14.6 6.8
800 JX 735 84
1
/ 50
2
10.5 14.3 7.0
800 HXL 735 84
1
10.5 14.3 7.0
900 HXL 810 84
1
16.0 19.8 5.1
1100 JX 1025 170
1
/ 85
3
16.0
1
/ 2.5
3
15.6
1
/ 2.4
3
6.4
1
/ ≈ 10
3
1100 JXL 1025 170
1
/ 85
3
16.0
1
/ 2.5
3
15.6
1
/ 2.4
3
6.4
1
/ ≈ 10
3
1400 JX 1270 170
1
/ 85
3
20.0
1
/ 3.2
3
15.7
1
/ 2.5
3
6.4
1
/ ≈ 10
3
1400 JXL 1270 170
1
/ 85
3
20.0
1
/ 3.2
3
15.7
1
/ 2.5
3
6.4
1
/ ≈ 10
3
1700 JXL 1560 200
1
/ 85
3
24.0
1
/ 3.2
3
15.4
1
/ 2.1
3
6.5
1
/ ≈ 10
3
1) These values apply to ALM+AIM combinations in Chassis format and do not take in account line-side fuse switch disconnectors or circuit breakers
2) These values apply to ALM+AIM combinations in Cabinet Modules format with fuse switch disconnectors including 3NE1 fuses in the LCM
3) These values apply to ALM+AIM combinations in Cabinet Modules format with circuit breaker in the LCM
SINAMICS S120 ALM+AIM: Maximum and minimum line-side short-circuit currents
1.2.5 Connection of converters to grounded systems (TN or TT)
On SINAMICS units connected to grounded TN or TT systems, it is basically possible to connect a ground fault
monitor capable of early detection of high-impedance ground faults (universal-AC/DC-sensitive differential current
monitor or Residual Current Monitor RCM) to the converter input. However, this ground fault monitor is relatively
complicated to install owing to the need for a summation current transformer in the mains feeder cable. Furthermore,
the response threshold of the monitor must be adjusted according to the relevant plant conditions. This means, for
example, on drives with long shielded motor cables in the power range of the SINAMICS converters described in this
engineering manual, the response thresholds of 30 mA or 300 m which would be required to ensure personnel safety
and fire protection are not technically feasible (see also section "Line filters", subsection "Magnitude of leakage or
interference currents"). For this reason, it is not normal practice to use a ground fault monitor in the power range of
the SINAMICS converters described in this manual. However, as described above, suitable protection must be
provided on the line side to ensure that the substantial ground fault current caused by a low-impedance ground fault
or short circuit in the device is promptly interrupted.
