Communication
11.4 DR 3 Belt scale parameters
SIWAREX WT241
100 Manual, 05/2015, A5E36046748A
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Belt load factor for
speed correction
(Page 105)
Belt load in % of nominal
load.
Only relevant if no sensor
is present
(specified value or im-
ported from DR4)
FLOAT
4
rw
100
1032
Impulse constant
speed sensor
(Page 105)
Only relevant if a sensor
present
FLOAT
4
rw
1000.0
1034
Reserve
LONG
4
rw
0
1036
Initial zero calibration
digits (Page 105)
Calibration digits with
empty belt
LONG
4
rw
500000
1038
Calibration weight
(Page 106)
Specification in KG or LB
(depending on selected
unit for belt load)
FLOAT
4
rw
50
1040
Calibration load
(Page 106)
Value input, e.g. 35 kg/m
for calibration by test
chain
FLOAT
4
rw
0
1042
Calibration quantity
(Page 106)
Value input in KG or LB
(depending on selected
unit for belt load)
FLOAT
4
rw
0
1044
Span calibration
digits (Page 106)
ADC digits for test weight
Value input or imported
from DR4
LONG
4
rw
1000000
1046
Simulation mode
(Page 106)
Simulation (is enabled or
disabled via commands)
0: Simulation not permit-
ted
1: Only weight simulation
permitted, weight is im-
ported from DR16 if simu-
lation mode is enabled
2: Only speed simulation
permitted, speed is im-
ported from DR16 if simu-
lation mode is enabled
3: Both permitted
Weight and speed are
imported from DR16 if
simulation mode is ena-
bled
USHORT
2
rw
0
1048
Warm-up timer
(Page 107)
Status bit in DR30
"Warm-up time running"
remains TRUE for the
specified time (minutes)
USHORT
2
rw
30
1049
Interface for the legal
trade display
(Page 107)(available
soon)
0: HMI SecureDisplay at
ETHERNET
1: HMI SecureDisplay via
S7 interface
USHORT
0
rw
0
1050
HMI SecureDisplay string
header version
UBYTE[2]
2
1051
