Scale parameters and functions of the belt scale
8.10 Menu 2.2 Scale status
SIWAREX WT241
74 Manual, 05/2015, A5E36046748A
Status digital outputs
Current status of digital inputs DQ.0 to DQ.3. A green highlight-
ed flag stands for an activated output.
Status analog output
The actual value of the current (in mA) which is output at the
analog output.
2.2.3 Scale status 3 of 5
Overview of the status of limits
Flow rate < min. flow rate
Set in case minimum flow rate is underrun
Flow rate > max. flow rate
Set in case maximum flow rate is exceeded
Speed < min. speed
Set in case minimum speed is underrun
Speed < max. speed
Set in case minimum speed is exceeded
Belt load < Min. belt load
Set in case minimum belt load is underrun
Belt load < max. belt load
Set in case maximum belt load is exceeded
Zero range
Set in case belt load is within zero range
Zero setting active
Set in case automatic zeroing is active
Automatic zero-tracking
enabled
Set in case automatic zero-tracking is enabled
Totalizers active
Set in case totalizers are active
Totalized disturbed
Set in case totalizers are disturbed
Totalizers enabled
Set in case totalizers are unblocked
Belt is running
Signalsthe belt is runnings
> Min. belt load for totaliz-
ing
Set in case minimum belt load for totalizing is not underrun –
this is a condition for totalizing
2.2.4 Scale status 4 of 5
Further process values
Speed simulation active
Set in case simulation mode speed is active
