Siemens SIWAREX WT241 User Manual

Scale parameters and functions of the belt scale
8.10 Menu 2.2 Scale status
SIWAREX WT241
Manual, 05/2015, A5E36046748A 75
Load simulation active
Set in case belt load simulation mode is active
Stop watch active
Set in case stop watch has been started and is running e.g by
calibration
Clock error
Set in case RTC buffer was cancelled. Will be reset after setting
the time.
Trace active
Set in case trace is running
Error on digital input
Set in case an error occured due to a command set through
digital input.
Pulse signal for remote
totalizer
Set in case a digital output has been defined as pulse signal for
external totalizer and is running.
Please refer to menu 1.5.3 “Remote totalizer pulse signal”
Scale calibrated
Calibration of load and speed has been performed.
Service mode active
Service mode is activated.
Calibration procedure acti-
ve
Set in case calibration has been started.
Write protection active
Write protection is active
Error analog output
Analogue output is disturbed
Warm up time
Warm up time after power on is running
Start up
Weighing electronic is starting up or restoring of recovery point
was done. Will be reset after 5 seconds.
System fault
System is disturbed
2.2.4 Scale status 5 of 5
Further process values
Digits (unfiltered)
The unfiltered digit value (measurement of weight) is the internal
measured value immediately before filtering.
Digits (filtered)
The filtered digit value (measurement of weight) is the internal
measured value immediately after filtering.
Pulses per belt revolution
Number of sensor pulses per belt revolution.
Pulses / s
Current integer value of impulses per second.
No. of zero calibrations
Number of performed zero calibrations. Will be reset with restor-
ing the default values.
No. of span calibrations
Number of performed span calibrations. Will be reset with restor-
ing the default values.
