Installation
26
Building Technologies A6V10257473_b_en_--.doc
Fire Safety & Security Products 01.2010
XC1003-A, commissioning / connection / maintenance
The removable board holder (1) can be positioned, after screw unmounting (3), as
indicated below to reach the DIN rail (2).
ON
1 2
ON
1 2
13 3
2
Fig. 11 XC1003-A, removable stand in “Commissioning” position
