Siemens XC10 Series User Manual

Installation
27
Building Technologies A6V10257473_b_en_--.doc
Fire Safety & Security Products 01.2010
XC1003-A, batteries installation
4.5 Ah batteries:
1. Remove the holder (1)
2. Install the batteries (3) as shown below
3. Remount the holder (1)
7.2 Ah batteries:
1. Remove the parts (1) and (2)
2. Install the batteries (4) as shown below
ON
1 2
ON
1 2
2
ON
1 2
1
3
4
Fig. 12 XC1003-A, battery installation
