Operation
20221560E 43
Manual source select
Step through the list of sources using the PORT 1 or STBD 1
button. Select the wanted source by using the PORT 10 or
STBD 10 button.
– – indicates that no source is supplying the data available.
Notes !
1. Simrad products will be identified by the product name
provided the data is available on SimNet. If data is
provided via an NMEA0183 port on the autopilot
computer, the display will read NMEA-1 or NMEA-2.
NMEA2000 products will have a special ID.
2. See note on page 75 and note 3 below.
3. In the event the SimNet is not powered on, sources
supplying data to SimNet are not on or malfunctioning, or
there is no SimNet installed, it is possible to use any
control unit in the system to select NMEA sources. .The
source select displays are then available on all control
units.
Compass
Select the compass to be used if more than one compass is
connected.
Note! Compass can only be selected in STBY mode
NAV source
Select a source for NAV mode steering.
Position
Select the source for position data and NoDrift mode.
Wind Apparent
Select the source for Apparent Wind
Wind Calculated
Select the source for Calculated Wind data. The autopilot
uses internal source irrespective of the selected source.
