$ATADUMP OR 3ENDWAYPOINTS TOFROM
COMPATIBLEUNIT
Using the optional Remote cable 104.3000.002 or alter-
native cable as specified below, connect the cable to
the REMOTE port on both units i.e.
Sender: Pin 1 (TX A) to Receiver: Pin 3 (RX A)
Sender: Pin 2 (TX B) to Receiver: Pin 4 (RX B)
$ATADUMP TOFROM0#
A transfer cable can be made from the NMEA cable
and e.g. a 9-pin D-SUB connector.
Connect cable to the REMOTE port, as follows:
Sender: Pin 1 white (TX A) to PC RS232 serial port
RX D (pin 2).
Sender: Pin 2 brown (TX B) to PC RS232 serial port
GND (pin 5).
Receiver: Pin 3 yellow (RX A) from RS232 serial port
TX D (pin 3).
Receiver: Pin 4 green (RX B) from RS232 serial port
GND (pin 5).
PC: standard Windows Hyper Terminal or another ter-
minal suited for dumping data to a file. The setup of
the serial channel must be:
4800 baud, 8 data bit, no parity, 1 stop bit.
F Remember to stop the PC terminal after the transfer
is completed. The data file will otherwise continue to
be filled with NMEA data, which normally is send out
on the same data port.
