MANAGING THE CHART DATABASE
20221859 / F 109
When the selection is confirmed by tapping OK, a symbol for
the selected type of object will be placed in the display center,
and the Mariner Object dialog will be shown:
The object may now be located by the cursor or by entering
coordinates if the symbol is a single point.
The object is saved by tapping Save.
The Save Mariner Object dialog box for entering information
about the object is displayed.
Enter all information necessary for later identification of the
object, and tap OK to remove the dialog from the display.
The displayed attributes in the Save Mariner Object dialog are
dependent of which type of mariner objects you have selected.
The mariner object will now be displayed in the chart.
Information about the object is obtained by pressing the right
cursor key. Refer
