NAVIGATING WITH THE CS66
20221859 / F 77
The lower part of the window contains the waypoint table for
active route. When a new route is to be created, the waypoint
table is empty. This waypoint table may be removed from the
window by tapping the Route menu and toggling off the
Waypoints command.
The toolbar keys in Route Editor window have the following
function:
Key Function
Shortcut
key
Ref.
page
Drop down list used for selecting chart scale.
50
Selects the best scale available for the displayed
area.
51
Displays the Chart presentation settings
dialog.
43
Checks the legs.
84
Prints the route.
91
Reverses route.
90
Displays the Move View to Route dialog.
53
Displays the Route Settings dialog used for
default route settings.
79
The Route Editor window is closed by tapping the in the
window’s upper right corner, or by selecting the Route menu
followed by the Close window command.
If the window is closed before a route is saved, the route
command will be aborted.
