Troubleshooting and Maintenance
974-24007001/5.0 91
No catch indication but
Depth and Temp are OK.
Ensure catch sensors are properly charged and display
of catch data is enabled.
Check unit on deck with catch sensor placed 1 meter
from receive transducer. Connect wire from “+” lug
to metal lid on back of catch sensor, wait a couple
minutes and verify display. If no indication or
indication is wrong, then fault is with the internal
sensor module.
NOTE: If the FS unit is diagnosed as being faulty, then the unit(s) should be
returned to an authorized Simrad service centre. ALL system performance results
and a complete description of the problem should be supplied with the defective unit
to assist in its repair.
5.5 Catch sensors
Refer to your SIMRAD FA or PI Sensor Operator and Service Manual.
5.6 Winch slip-rings and trawl cable
Refer to your Manufacturer Operator and Installation Manual.
