FS 70 System Operation
974-24007001/5.0 25
3.2.4.1 Using the reference cursors:
The Reference Cursors are two cross-hair type markers that can be placed on the sonar
image to mark a point of interest. User can use the reference cursors to measure the range
and bearing from the origin.
Reference cursor 1
Reference cursor 2
To use the reference cursors, click the Cursors button from the Display tab
