FS 70 System Operation
974-24007001/5.0 37
The slider bar shows the relative progress of the playback. The markers on top of the slider
bar correspond to the beginning of each volume or file in the selected file group. The slider
can be dragged ahead or back to see any part of the data.
Select Restart from beginning of Volume if you want to always restart at the beginning of
each volume after repositioning the slider bar. This is the default and provides the fastest
repositioning. If this option is disabled, the system will fast forward through the selected
volume to the user selected position.
The Progress box shows the playback progress as a percentage of the total file group size.
Select Continuous to allow the system to continuously replay the same file group over and
over again.
The date and time of the recorded data are displayed as GMT time.
Use the Fast Forward Speed control to adjust the playback speed when the Fast Forward
feature has been selected.
3.2.6.3 Exporting
To start exporting, click on the recording toolbar.
The Export Sensor Selection dialog box allows you to configure the system to export data
to a COM port.
Select a COM port under Ports and check Enabled Export On Port. Select one or more
data source under Select Source.
