Simrad GC80/85 Double System Controller
36
988-12721-001
INS (BAMS)
Circuits: ...................................................................................................... 1
Electrical: ................................................................. RS422/ NMEA0183
Baud rate: .................................................................................. 4800 bps
Data bits: ........................................................................................... 8 bits
Parity: .................................................................................................. None
Stop bits:.................................................................................................... 1
Transmit freq.: ....................................................... INDETERMINATELY
Input format:
$--ACN,xxxxxx.xx,aaa,x.x,x.x,a,C*hh<CR><LF>
$--HBT,x.x,a,x*hh<CR><LF>
PULSE signal (LOG)
Circuits: ...................................................................................................... 1
Electrical: ............................................ 200/400 p.p.n.m., dry contact
Voltage/Current: ..................................................................... 5 V/5 mA
Heading sensor select
Circuits: ...................................................................................................... 2
Voltage/Current: ................................................................. 32 V/20 mA
Alarm ACK
Circuits: ...................................................................................................... 1
Voltage/Current: ..................................................................... 5 V/5 mA
Buzzer stop
Circuits: ...................................................................................................... 1
Voltage/Current: ..................................................................... 5 V/5 mA

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
