Simrad GC80 User Manual

Simrad GC80/85 Double System Controller
50
988-12721-001
TB21
PIN NO NAME DETAILS
1 11TX+ Serial signal output (RS422+): selected sensor
2 11TX- Serial signal output (RS422-): selected sensor
3 11TSC Serial signal output (GND)
4 12TX+ Serial signal output (RS422+): selected sensor
5 12TX- Serial signal output (RS422-): selected sensor
6 12TSC Serial signal output (GND)
7 13TX+ Serial signal output (RS422+): selected sensor
8 13TX- Serial signal output (RS422-): selected sensor
9 13TSC Serial signal output (GND)
10 14TX+ Serial signal output (RS422+): selected sensor
11 14TX- Serial signal output (RS422-): selected sensor
12 14TSC Serial signal output (GND)
13 15TX+ Serial signal output (RS422+): selected sensor
14 15TX- Serial signal output (RS422-): selected sensor
15 15TSC Serial signal output (GND)
16 16TX+ Serial signal output (RS422+): selected sensor
17 16TX- Serial signal output (RS422-): selected sensor
18 16TSC Serial signal output (GND)
19 17TX+ Serial signal output (RS422+): selected sensor
20 17TX- Serial signal output (RS422-): selected sensor
21 17TSC Serial signal output (GND)
22 18TX+ Serial signal output (RS422+): selected sensor
23 18TX- Serial signal output (RS422-): selected sensor
24 18TSC Serial signal output (GND)
TB22
PIN NO NAME DETAILS
1 19TX+ Serial signal output (RS422+): selected sensor
2 19TX- Serial signal output (RS422-): selected sensor
3 19TSC Serial signal output (GND)
4 20TX+ Serial signal output (RS422+): selected sensor
5 20TX- Serial signal output (RS422-): selected sensor
6 20TSC Serial signal output (GND)
7 21TX+ Serial signal output (RS422+): selected sensor

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
