Simrad GC80 User Manual

Simrad GC80/85 Double System Controller
988-12721-001
49
PIN NO NAME DETAILS
7 G2SC Internal communication serial signal GND
8 G2SEL1
Selection signal input (potential free contact)
9 G2SEL2
10 E2SEL1
External heading selection signal input
(potential free contact)
11 E2SEL2
12 G2ALCN1
Alert signal output (potential free contact)
13 G2ALCN2
14 G2RNCN1
Running signal output (potential free contact)
15 G2RNCN2
16 Not used -
TB3
PIN NO NAME DETAILS
1 P_RX+
Extension of operation panel internal communication
serial signal input
2 P_RX-
3 P_SC Extension of operation panel internal communication
serial signal GND
4 P_TX+
Extension of operation panel internal communication
serial signal output
5 P_TX-
6 P_24 V Extension of operation panel power supply output 24
V DC
7 P_GND Extension of operation panel power supply output
GND
8
9 P_G124 V
Not used
10 P_G1CN
11 P_G224 V
12 P_G2CN
13 P_E24 V
14 P_ECN
15 P_GGND
16 P_EGND

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
