Simrad GC80 User Manual

Simrad GC80/85 Double System Controller
74
988-12721-001
Alert detected in GC80/85 Expanded No.1
Alarm
code
Name Detailed code*1 Priority Category Troubleshooting
300 NO1GYRO MAIN PWR E-2 Warning A
TS-24
301 NO1GYRO PWR FAIL E-2 Warning A
302 NO1GYRO INVERTER E-2 Warning A
303 NO1GYRO CONT. PWR E-2 Warning A
304 NO1GYRO ROTOR E-2 Warning A
305 NO1GYRO LEVEL E-2 Warning A
306 NO1GYRO SERVO E-2 Warning A
307 NO1GYRO EEPROM E-2 Warning B
308 NO1GYRO INN.COM1 E-2 Warning A
309 NO1GYRO INN.COM2 E-2 Warning A
310 NO1GYRO GPS COMM E-2 Warning B
311 NO1GYRO GPS DATA E-2 Warning B
312 NO1GYRO LOG COMM E-2 Warning B
313 NO1GYRO LOG DATA E-2 Warning B
318 NO1GYRO E5V E-2 Warning A
319 NO1GYRO STEP ERR. E-2 Warning A
320 NO1GYRO ZERO ERR. E-2 Warning B
321 NO1GYRO DGC COMM E-2 Warning A
Alert detected in GC80/85 Expanded No.2
Alarm
code
Name Detailed code*1 Priority Category Troubleshooting
500 NO2GYRO MAIN PWR E-2 Warning A
TS-24
501 NO2GYRO PWR FAIL E-2 Warning A
502 NO2GYRO INVERTER E-2 Warning A
503 NO2GYRO CONT.PWR E-2 Warning A
504 NO2GYRO ROTOR E-2 Warning A
505 NO2GYRO LEVEL E-2 Warning A
506 NO2GYRO SERVO E-2 Warning A
507 NO2GYRO EEPROM E-2 Warning B
508 NO2GYRO INN.COM1 E-2 Warning A
509 NO2GYRO INN.COM2 E-2 Warning A
510 NO2GYRO GPS COMM. E-2 Warning B

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
