Simrad GC80 User Manual

Simrad GC80/85 Double System Controller
988-12721-001
73
Alarm
code
Name Detailed code*1 Priority Category Troubleshooting
101 NO.1 SCC COMM. E-1
Alarm
Warning
B TS-05
102 NO.2 SCC COMM. E-1
Alarm
Warning
B TS-06
100 PANEL COMM. E-2 Warning B TS-07
107 DGCIF COMM. E-1
Alarm
Warning
B TS-08
110 G1 PWR 24 V E-2 Warning B TS-11
111 G2 PWR 24 V E-2 Warning B TS-12
113 IF PWR NO.1 E5 V E-2 Warning B TS-14
114 IF PWR NO.2 E5 V E-2 Warning B TS-15
115 IF PWR DGC E5 V E-2 Warning B TS-16
116 IF PWR NO.1 +12 V E-2 Warning B
TS-17
117 IF PWR NO.1 -12 V E-2 Warning B
118 IF PWR NO.2 +12 V E-2 Warning B
TS-18
119 IF PWR NO.2 -12 V E-2 Warning B
120 SENSOR SWITCH TS-19
123 NO.1 SCC WDT - Caution B
TS-20
124 NO.2 SCC WDT - Caution B
125 Master WDT - Caution B
126 Slave WDT - Caution B
134 GNSS comm. E-2 Warning B
135 NO.1 GNSS comm. E-2 Warning B
136 NO.2 GNSS comm. E-2 Warning B
137 LOG comm. E-2 Warning B
138 NO.1 LOG comm. E-2 Warning B
139 NO.2 LOG comm. E-2 Warning B
140 Pilot comm. - Caution B
141 INS comm. - Caution B
142 NO.1 INS comm. - Caution B
143 NO.2 INS comm. - Caution B
250 Integrity failed E-2 Warning B TS-21
251 Integrity doubtful 1 E-2 Warning B TS-22
252 Integrity doubtful 2 E-2 Warning B TS-23

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
