Simrad GC80 User Manual

Simrad GC80/85 Double System Controller
988-12721-001
15
3 USER INTERFACE
This section gives an overview of the GC80/85 Double System Controller
unit and the user interface.
3.1 General
The Double System Controller unit includes 1 control panel.
3.2 Control panel
The control panel includes the buttons described on the following pages.
Heading sensor indicators
NO.1 indicator
Indicates the status of the NO.1 gyrocompass:
- Green LED: Normal operation
- Red LED: Error
- OFF: Not installed
Refer to “Select heading sensor” on page 20.
NO.2 indicator
Indicates the status of the NO.2 gyrocompass:
- Green LED: Normal operation
- Red LED: Error
- OFF: Not installed
Refer to “Select heading sensor” on page 20.

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
