Simrad GO7 User Manual

Extension lines
A: Heading
B: Course Over Ground (COG)
The lengths of the extension lines are either set as a fixed distance,
or to indicate the distance the vessel moves in the selected time
period. If no options are turned on for the vessel then no extension
lines are shown for your vessel.
Your vessel heading is based on information from the active
heading sensor and the COG is based on information from the
active GPS sensor.
Synchronize 2D/3D chart
Links the position shown on one chart with the position shown on
the other chart when a 2D and a 3D chart are shown side by side.
Pop-up information
Selects whether basic information for chart items is displayed when
you select the item.
Grid lines
Turns on/off viewing of longitude and latitude grid lines on the
chart.
Waypoints, Routes, Tracks
Turns on/off displaying of these items on chart panels. Also opens
the Waypoints, Routes and Tracks dialogs you can use to manage
them.
Charts | GO7 Operator Manual
41

Simrad GO7 Specifications

General

Resolution	800 x 480 pixels
Touchscreen	Yes
Networking	NMEA 2000
Bluetooth	Yes
Chartplotter	Yes
Display Size	7 inch
GPS Type	Internal
Wireless Connectivity	Wi-Fi
Chart Compatibility	C-MAP, Navionics
Display Type	TFT LCD
SD Card Slots	1
Sonar Compatibility	CHIRP
Radar Compatibility	Yes
Operating Temperature	-15°C to 55°C
Sonar	Broadband, CHIRP, DownScan, SideScan (with compatible transducer)
