Simrad NX40/45 Installation and Operation Manual104
Specications21
GENERAL
NX45 Size: 256 mm (10.08“) H x 385
mm (15.16“) W x 78.5 mm (3.09“)
D. Allow 3 mm clearance on each side
for the cover.
NX45 Display: 307 mm (12.1”)
diagonal, TFT color, 800 x 600 pixels.
NX40 Size: 190 mm (7.48“) H x 285
mm (11.22“) W x 76.8 mm (3.02“)
D. Allow 3 mm clearance on each side
for the cover.
NX40 Display: 213.4 mm (8.4”)
diagonal, TFT color, 800 x 600 pixels.
Backlight: Display and keys
Supply voltage: 10.5 to 32 V DC.
Supply current: at 13.8 V
350 mA min - no backlighting.•
1A max - full backlighting.•
External beeper or light output:
Switched to ground to sound alarm,
30 V DC, 200 mA maximum.
Operating temperature: 0° to 50°C (32°
to 122°F)
ALARMS
User set: Arrival radius, anchor, XTE, •
danger, too shallow, too deep, sh,
temperature, temperature rate, low
battery, low fuel (optional), loss of
DGPS x, radar guard zone, dangerous
AIS vessels.
GPS NAVIGATION
Chart card: C-MAP™ SD Card (NT MAX,
NT+ or NT)
User card: SD Card
Waypoints: Up to 3000, with default
or user-dened alphanumeric names
up to eight characters.
Routes: 99 Routes, with up to 500
points each
Tracks: By time or distance, 10 tracks
of 2000 points.
Chart datums
121 Chart datums (see next page)•
One user-dened map shift.•
Chart scale: 0.05 to 4096 nm for chart
(chart dependent) down to 0.01 nm
in plotter mode.
ECHOSOUNDER FISHFINDING
(Optional depth transducer required)
Depth range: 1 m (3 ft) to 1000 m
(3300 ft )
Sounder output:
Power: Variable, up to 600/1000 W •
RMS
Dual frequency: 50 kHz and 200 kHz•
Depth acquisition time from startup:
Typically 2 seconds at 30 m (100 ft)•
Temperature:
Range 0° to 37.7°C (32° to 99.9°F)•
Resolution of 0.1° unit.•
Speed (from paddlewheel transducer):
1 to 96.6 kph (57.5 mph, 50 kn).•
FUEL COMPUTER
(Optional fuel sensor(s) required)
Engine types:
Outboard carburetted two stroke and •
EFI petrol/gasoline engines: 50 to 300
hp.
Outboard four stroke petrol/gasoline •
engines: 90 to 300 hp.
Inboard petrol/gasoline engines: 70 •
to 400 hp.
Flow rate:

Simrad NX40 Specifications

General

Brand	Simrad
Model	NX40
Category	Marine Equipment
Language	English
