Simrad NX40/45 Installation and Operation Manual 21
A typical chart window shows:
A Data header. To turn the data off or on or to change
what data is shown
B Compass
C Chart scale
D Boat position
E Boat track
F Boat course and CDI lines
G Distance and bearing of cursor from boat
H Land
I Sea
J The cursor
K A typical waypoint
A
B
C
G
I
H
E
D
J
K
F
F
CAUTION
!
!
CAUTION
DANGER
WARNING
The built-in world chart
does not show enough
detail for navigation. When
you use the NX40/45 to
navigate, always use a
chart card which covers
the region.
3-2 Chart window
To go to the Chart window
> Chart
