Fuel functions and display14
The Fuel functions require optional petrol/gasoline or
SmartCraft fuel sensors to be installed and set up.
13-1 What the fuel computer does
Each engine has a ow sensor installed to measure the
engine’s fuel ow.
The NX40/45 use these ows, together with boat speed
and engine RPM if available to estimate the fuel remaining
in the tank(s), fuel used, range and fuel economy. This
data is shown on the fuel display.
You can:
display the fuel used during a trip.•
set low fuel alarms.•
make fuel consumption curves - graphs of fuel •
consumption and boat speed as a function of engine
RPM - to monitor and optimize boat performance.
13-2 Fuel display
To go to the Fuel display
> More > Fuel
The display differs according to the number of engines
and tanks.
To switch between a Summary or a Fuel curve
display
If engine RPM is available and if you have made and
selected a Fuel Consumption Curve.
The Fuel display shows:
Speed
RPM (if available)
If engine RPM is not available, the display shows depth.
Remaining
The fuel remaining in the tank(s) is shown as a vertical
gauge on the right of the display. The height of the yellow
bar(s) show how much fuel remains in the tank(s). If you
have set a low fuel alarm, a red bar shows the level at
which the alarm will trigger. If there are two tanks, the
left bar shows the port tank, the right bar shows the
starboard tank.
