Simrad NX40/45 Installation and Operation Manual80
Lat/long grid displays a latitude and longitude
grid.
Boundaries Displays boundaries around areas
where more detailed chart coverage
is available: Auto shows the next four
detail levels; On shows all.
Text/icon size Select the size of chart text and
icons.
Water submenu
Water features
displays nature of sea bed (for
example, M shows areas of mud) and
tide station icons.
Bathymetric[s] lines Displays underwater depth
contours between Bath & dndgs min
and max.
Spot soundings Displays underwater depth contours
between Bath & dndgs min and max.
Bath & sndgs min The minimum depth for
Bathymetrics and Spot soundings.
Bath & sndgs max The maximum depth for
Bathymetrics and Spot soundings.
Tidal stream
displays dynamic tide flows: arrows
on a chart showing the present tide
stream and orientation (requires a
GPS fix and an NT MAX card)
Land submenu
Land features displays land features, for example
regions, rivers, roads, railways,
airports.
Land elevation
displays land contours, shaded like
depths (requires an NT Max card)
Other submenu
Waypoints Displays waypoints: Hide all only
displays waypoints on any selected
route; Selected displays waypoints
with their display option set to Icon
or I+N (Icon and Name); Show all
displays all waypoints.
Names
displays place names.
Lights Light House window options: Off
hides all light indicators (the icon still
shows); No sectors hides sectors; On
shows sectors; Animated activates
light animation.
Note: with light animation enabled,
animation only operates chart.
Nav-aids Displays signals (fog, radar, radio
stations) and buoys. Int and US
select the icon format; Simpl draws
simpler icons.
