Description

Selectapalettetosuittheambientlightconditionsand

yourpersonalpreferences.Thechoiceyoumakedoesnot

haveanyeffectontheTV80performance.

Relatedtopics

Changingthecolourpalette("skin")usedintheTV80

presentations,page82

Unitsdialogbox

ThechoicesintheUnitsdialogboxallowyoutocontrolwhichunitsofmeasurements

thatareused.

Howtoopen

ThisdialogboxisopenedfromtheDisplaymenu.

Description

TheTV80ispreparedtoworkwithseveralinternationalstandardsforunitsofmeasurements.

UsetheUnitsoptionstoselecttheunitsofmeasurementsyouwishtoworkwith.TheTV80

usestheseinallpresentations.Youonlyneedtodenetheseonce.Usethedropdownlists

providedtomaketheselections.
