224

406388/B

NewLayout

OntheTV80youcancreateasmanylayoutsasyouneedtosuityourpersonaloroperational

preferences.IntheNewLayoutdialogboxyoucancreateanewlayoutchoosingonefrom

theeightpossibleviewcombinations.Giveitatitle-orname-and,ifyoundituseful,

youcanassignafunctionkeytoit.

TheNewLayoutdialogboxislocatedintheLoadLayoutdialogbox.Toopen,selectLoad

LayoutintheDisplaymenu.

Description

Inthiscontext,thedifferentcombinationsofviewsiscalledlayout.Ifyouareworkingwith

manysensors,youmaynditusefultoworkwithdifferentsensorsviewscombinations

dependingontheoperatingscenario.Youcancreateanewlayoutanytimeyouneedit

tomakeyouroperationseasier.

Details

Title

Wheneveryoudeneanewlayout,youmusttogiveitatitle-orname–.Thiswill

helpyouidentifyit.Typeatitleinthespaceprovided.

Tip

IfyoudonothaveacomputerkeyboardconnectedtoyourTV80system,selectthe

Keyboardbuttontoopenanon-screenkeyboard.

SimradTV80ReferenceManual
