124
4, Dis-assembled Acufeed Assy.
5, Remove the counter balance spring first from the hole hung on the front side of Accufeed,
and then remove the feeler after pressing the hook on Auto compressure.
6, Remove Acufeed unit with the harness separated, and then 2 paper detection sensors.
