15 Extra equipment and accessories Sirona Dental Systems GmbH
15.6 X-ray image viewer on the lamp support tube C3
+
59 06 404 D 3390
116 D 3390.201.01.18.02
15.6 X-ray image viewer on the lamp support tube
Extra equipment
This X-ray image viewer is switched ON or OFF using
the illustrated key on the dentist or assistant element
control panel.
To view intraoral dental images the anti-glare film (1)
must first be attached with two clips. Then fasten the
intraoral dental images with the third clip over the
cut-out.
15.7 Tray (extra equipment)
Place the tray in position and clamp it with the lever (2).
The tray is available in two different sizes:
Small tray – 185 x 286 mm
REF: 60 47 992
Large tray – 297 x 385 mm
REF: 60 48 008
