Sirona C3 Plus - SIROCAM Integrated in Dentist Element (PC); PC Mode Operation and Image Saving

14 SIVISION 3 / SIROCAM 3 / SIROCAM C Sirona Dental Systems GmbH
14.7 SIROCAM 3 / SIROCAM C integrated in the dentist element (PC) C3
+
59 06 404 D 3390
98 D 3390.201.01.18.02
14.7 SIROCAM 3 / SIROCAM C integrated in the dentist element (PC)
Operation in PC mode using a
PC connection and SIDEXIS/VIDEXIS
The monitor is controlled by the PC in this case.
The functional scope of the PC can be used in this mode.
If the camera is the active instrument "VIDEOCAM" and
the operating mode "PC MODE" appear on the display.
Picking up the camera
•The LIVE IMAGE window opens.
TOGGLING BETWEEN STILL IMAGE AND LIVE
With the camera picked up, the cursor is in the instru-
ments key block.
Step on the foot pedal.
Toggling between a STILL IMAGE and a LIVE IMAGE.
SIVISION
A
VIDEOCAM
PC MODE
SIVISION
SIVISION
C
+
C
