Sirona C3 Plus - Mode: White Balance and Instrument Settings

11 Basic treatment center settings in the Mode dialog Sirona Dental Systems GmbH
11.9 Mode: BOWL FLUSH. ON S YES - NO C3
+
59 06 404 D 3390
68 D 3390.201.01.18.02
11.9 Mode: BOWL FLUSH. ON S YES − NO
Cuspidor flushing with chair program S
In program S of the treatment chair, cuspidor flushing
switches on.
11.10 Mode: CUP FILL ON S YES – NO
Tumbler filling function with chair program S
If you want the tumbler to be filled in program S of the
treatment chair.
11.11 Mode: WHITE BALANCE
White balance (only with an integrated
SIROCAM 3)
This Mode dialog is only displayed in connection with an
integrated SIROCAM 3.
The camera handpiece contains data that makes it pos-
sible to restore the factory-set color definitions regard-
less of the dental treatment center where the camera is
used.
Thus the camera can be used at different dental treat-
ment centers.
For adjustments, e.g. if you wish to set individual colors,
you must perform a white balance.
Select the "TAKE VCAM" display in the Mode dialog.
When you pick up the camera, the dialog for performing
the white balance is displayed.
There are 3 options available:
The display shows the current camera status, i.e., if an
individual white balance was performed the last time,
USER is displayed in bold type.
If the factory settings are valid, HOME is displayed in
bold type.
A
BOWL FLUSH ON S
YES – NO
BOWL FLUSH ON S
YES – NO
Mode
–
+
A
CUP FILL ON S
YES – NO
CUP FILL ON S
YES – NO
Mode
–
+
Mode
–
+
A
WHITE BALANCE
HOME – USER – EXIT
WHITE BALANCE
HOME – USER – EXIT
A
TAKE VCAM
HOME – USER – EXIT
HOME - factory settings (can be restored at any
time)
USER - individual white balance
EXIT - to exit the WHITE BALANCE dialog.
