8 Positioning patients Sirona Dental Systems GmbH
8.1 Articulated headrest C3
+
59 06 404 D 3390
40 D 3390.201.01.18.02
8 Positioning patients
8.1 Articulated headrest
The headrest must be adjusted manually.
To do this, take the load off the backrest and pull out or
push in the headrest using the handle (1).
Tilt the headrest backward using the locking button (2).
Tilt the headrest forward by simply pulling it out.
8.2 Flat headrest
The headrest must be adjusted manually.
To do this, take the load off the backrest and pull out or
push in the headrest using the handle (1).
The head pad (2) is held magnetically.
The head pad (2) contains a strong magnet on its
bottom side. This magnet could affect any cardiac pace-
maker located nearby.
Therefore, do not allow patients, users, and technical
personnel with a cardiac pacemaker to be located near
this magnet.
Furthermore, direct contact of the head pad with mag-
netic cards can lead to data loss.
