Sirona Dental Systems GmbH 4 Controls and functional elements
C3
+
4.3 Control panel on the assistant element
59 06 404 D 3390
D 3390.201.01.18.02
27
Additional functions – light blue keys
Tumbler filling
ON / OFF
Flushing of the cuspidor
ON / OFF
X-ray image viewer
ON / OFF
The video system also has WHITE SCREEN activation
Sanitation of water lines
This key can be used to start the treatment center sani-
tation program (see the document "Care and Cleaning
by the Practice Team").
Freely selectable function
The function can be preset as a button or switch in the
Mode dialog.
Freely available relay 230 V, 6 A
(connected by the service engineer).
Light ON/OFF
With SPRAYVIT picked up: Instrument light
With SPRAYVIT in holder: Operating light
