CAUTION: Too much tension will result in power loss and exces-
sive stresses on suspension components.
To adjust track tension:
– R emo ve the tether co rd cap .
– On some models, remove rear wheel caps.
– Loosen the rear idler wheel retaining screws.
– Loosen the lock nuts (on so equipped models) then turn adjust-
ment screws to adjust.
If correct t ension is unattainable, contact an authorized SKI-D OO
dealer.
1
2
3
A05F0EA
TYPICAL
1. Adjustment screw
2. Loosen lock nut (on so equipped models)
3. Loosen screw
– Retighten retaining screws and lock nuts (on so equipped mod-
els).
– Check track alignment as described below.
214
