Skyjack SJ6832 RTE Series User Manual

Rough Terrain Electric Scissors
December 2007 Page 75
Section 5 Labels
Labels - Model 6832RTE
2 1 3
No. Label Pictorial Description
1
Warning - Electrical Shock
Stay away. High voltage (48V).
2
No Pressure Washer
Do not use pressure washer.
3
Battery Cover Lock
Turn knob “ ” to the left to unlock battery tray cover.
Turn knob “ ” to the right to lock battery tray cover in place.
Battery/Electrical Compartment

Skyjack SJ6832 RTE Series Specifications

General

Working Height	38 ft
Platform Height	32 ft
Lift Capacity	1, 000 lbs
Drive Speed	3.5 mph
Gradeability	30%
Drive Speed (Stowed)	3.5 mph
Maximum Working Height	38 ft
Capacity	1, 000 lbs
Overall Width	68 in
Weight	3, 629 kg
Drive Speed (Elevated)	0.8 km/h
Turning Radius (Outside)	4.27 m
Fuel Tank Capacity	45.4 L
Platform Length	2.44 m
Platform Width	0.76 m
Power Source	Diesel / Electric
Overall Length	130 in
Stowed Height (Rails Up)	2.08 m
Stowed Height (Rails Folded)	1.85 m
Turning Radius (Inside)	5 ft
