ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 40 of 83
Category
Parameters
Range
Default
Description
exceeds full charged limit,
controller will start trickle
charging countdown.
Under
Battery
Voltage Start
Delay
(0~3600)s
30
It is the time from controller
detects battery under
voltage start signal to
genset starts up, or time
from battery under voltage
start charging completely to
genset ready to stop.
Under
Battery Volt.
Start On
Load
(0~1)
0
0 Disabled 1 Enabled
If enabled, genset under
voltage start allows
ramp-on load, otherwise,
only charging function is
permitted and lights are off.
Under Speed
Shutdown
Enable
(0~1)
1
0 Disabled 1 Enabled
Set Value
(0~200)%
80
The setting value is
percentage of rated speed.
Delay
(0~3600)s
10
Over Speed
Shutdown
Enable
(0~1)
1
0 Disabled 1 Enabled
Set Value
(0~200)%
114
The setting value is
percentage of rated speed.
Delay
(0~3600)s
2
Under Speed
Warning
Enable
(0~1)
0
0 Disabled 1 Enabled
Set Value
(0~200)%
86
The setting value is
percentage of rated speed.
Return Value
(0~200)%
90
The setting value is
percentage of rated speed.
Delay
(0~3600)s
3
Over Speed
Warning
Enable
(0~1)
0
0 Disabled 1 Enabled
Set Value
(0~200)%
110
The setting value is
percentage of rated speed.
Return Value
(0~200)%
108
The setting value is
percentage of rated speed.
Delay
(0~3600)s
5
Loss of Speed
Signal
Action
(1~2)
1
1 Warning 2 Shutdown
Delay
(0~3600)s
5
It is time from controller
detects that speed is 0 to
action confirmed.
Overshoot
Set Value
(0~20)%
10
If set as 0%, which means
this function is disabled.
Delay
(0~3600) s
2
