ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 43 of 83
Category
Parameters
Range
Default
Description
frequency, genset will not
enter into normal running
status.
Voltage
Transformer(PT)
Enable
(0~1)
0
0 Disabled 1 Enabled
PT Primary
(10~1000)V
110
PT Secondary
(10~1000)V
110
Gen. Under Voltage
Shutdown
Enable
(0~1)
1
0 Disabled 1 Enabled
Set Value
(0~200)%
80
The setting limit is
percentage of generator
rated voltage.
Delay
(0~3600)s
10
Gen. Over Voltage
Shutdown
Enable
(0~1)
1
0 Disabled 1 Enabled
Set Value
(0~200)%
120
The setting limit is
percentage of generator
rated voltage.
Delay
(0~3600)s
5
Gen. Under
Frequency
Shutdown
Enable
(0~1)
1
0 Disabled 1 Enabled
Set Value
(0~200)%
80
The setting limit is
percentage of generator
rated frequency.
Delay
(0~3600)s
10
Gen Over
Frequency
Shutdown
Enable
(0~1)
1
0 Disabled 1 Enabled
Set Value
(0~200)%
114
The setting limit is
percentage of generator
rated frequency.
Delay
(0~3600)s
3
Gen Under Voltage
Warning
Enable
(0~1)
1
0 Disabled 1 Enabled
Set Value
(0~200)%
84
The setting limit is
percentage of generator
rated voltage.
Return
(0~200)%
86
The setting limit is
percentage of generator
rated voltage.
Delay
(0~3600)s
5
Gen Over Voltage
Warning
Enable
(0~1)
1
0 Disabled 1 Enabled
Set Value
(0~200)%
110
The setting limit is
percentage of generator
rated voltage.
Return
(0~200)%
108
The setting limit is
percentage of generator
rated voltage.
Delay
(0~3600)s
3
