The SmartRG front panel LEDs are defined as follows:
ON: Power is on
OFF: Power is off
ON: Ethernet WAN Active
OFF: No link
ON: Link established and active
OFF: No link
Blinking: Training mode
ON: Internet connection established
OFF: No Internet connection
Blinking: Data transfer on WAN Internet connection
RED: PPP authentication failure
ON: LAN link established and active
OFF: No LAN link
BLINKING: Data transfer on LAN port
ON: WLAN enabled
OFF: WLAN disabled
Blinking: data transfer currently occurring over the WiFi interface
