SmartRG gateways are designed to exceed the high bandwidth demands of either IPTV service
architecture. Refer to the appropriate section below to configure the SmartRG gateway for your
particular IPTV deployment architecture.
Bridged IPTV Configuration
A bridged IPTV configuration is comprised of:
one (or more) WAN connections
one (or more) LAN connections –and-
an interface grouping structure to bind all of the connections together
The more generalized bridged IPTV service configuration with multiple WAN connections is shown
below.
Figure 27 Multi-WAN Connection Bridged IPTV Configuration
