B
ASIC
C
ONFIGURATION
3-17
CLI – Enter the following command.
Setting the Switch’s IP Address
This section describes how to configure an IP interface for management
access over the network. The IP address for this switch is obtained via
DHCP by default. To manually configure an address, you need to change
the switch’s default settings (IP address 0.0.0.0 and netmask 255.0.0.0) to
values that are compatible with your network. You may also need to a
establish a default gateway between the switch and management stations
that exist on another network segment.
You can manually configure a specific IP address, or direct the device to
obtain an address from a BOOTP or DHCP server. Valid IP addresses
consist of four decimal numbers, 0 to 255, separated by periods. Anything
outside this format will not be accepted by the CLI program.
Command Attributes
• Management VLAN – ID of the configured VLAN (1-4094, no
leading zeroes). By default, all ports on the switch are members of
VLAN 1. However, the management station can be attached to a port
belonging to any VLAN, as long as that VLAN has been assigned an
IP address.
• IP Address Mode – Specifies whether IP functionality is enabled via
manual configuration (Static), Dynamic Host Configuration Protocol
(DHCP), or Boot Protocol (BOOTP). If DHCP/BOOTP is enabled,
IP will not function until a reply has been received from the server.
Console#show bridge-ext 4-218
Max support VLAN numbers: 255
Max support VLAN ID: 4094
Extended multicast filtering services: No
Static entry individual port: Yes
VLAN learning: IVL
Configurable PVID tagging: Yes
Local VLAN capable: No
Traffic classes: Enabled
Global GVRP status: Disabled
GMRP: Disabled
Console#
