Scanner Demo OBD-II/EOBD Demonstration
18
6. Select Back to return to the OBD-II/EOBD Service menu.
7. Proceed to OBD-II/EOBD Demo 4.
z OBD-II/EOBD Demo 4 - Display Trouble Codes
This demonstration simulates a typical check of current OBD trouble codes.
1. From the OBD-II/EOBD Service menu select ($03) Display Trouble Codes.
A list of OBD trouble codes (DTCs) is displayed.
2. Select Back to return to the OBD-II/EOBD Service menu.
3. Proceed to OBD-II/EOBD Demo 5.
z OBD-II/EOBD Demo 5 - Find Trouble Code and Drive Cycle Information:
This demonstration walks you through a typical lookup of OBD trouble code
reference information and generic drive cycle information within Fast-Track
Troubleshooter.
1. From the OBD-II/EOBD Service menu select Fast-Track Troubleshooter
2. Select Engine.
3. Select *CODE TIPS
4. Select *P0xxx DTC TIP LISTS
5. Select *P02xx FUEL & AIR METERING
6. Select P0265
A brief code description is given along with possible causes.
7. Select the Save Note icon to save the note for review* later.
8. Select Back until you return to the OBD-II/EOBD Service menu.
9. Proceed to OBD-II/EOBD Demo 6.
z OBD-II/EOBD Demo 6 - Display and Save Freeze Frame Data:
This demonstration walks you through a typical check of OBD Freeze Frame data,
and shows how to save and review the data.
1. From the OBD-II/EOBD Service menu select ($02) Display Freeze Frame
Data.
A freeze frame list of data is displayed. Note: Use the scroll bar to view all the
data.
2. Select Save . A confirmation message will briefly display to inform you that
a file has been saved.
3. Select Back once, then press Home once to return to the Home
screen.
4. From the Home screen select Previous Vehicles and Data .
5. Select View Saved Data.
A list of all saved files is displayed (most current at top). OBD-II/EOBD Freeze
Frame files are saved with an .SCM file extension, show the date saved and
are labeled OBD.
6. Select the saved Freeze Frame file to view it.
Notes:
• Use the scroll bar to view all the data in the file, if needed.
• Use the navigation controls to navigate through the data.
7. Select Back once, then press Home once to return to the Home
screen.
End of OBD-II/EOBD demonstration.
To Next Page
