40
Scanner Operations
Saving
The Save button is used to record movies of vehicle datastream values. Saving helps when trying
to isolate an intermittent problem or to verify a repair during a road test. Saved files also provide
documentation that helps you explain intermittent problems to your customers.
A number of data movies can be stored, which can later be opened by selecting the Previous
Vehicles and Data button on the home screen.
Saved files can also be downloaded to a personal computer (PC) through the Mini USB port. Once
connected to the PC, files can be printed, transferred, and copied using ShopStream Connect.
ShopStream Connect is an application that creates an interface between the diagnostic tool and
a PC.
ShopStream Connect is a free download available at: https://www1.snapon.com/ukssc.
z To save a movie:
• Select Save.
A save movie dialog box displays while data is being saved. The movie is saved when the
message box disappears.
Figure 5-16 Sample save dialog box
i The Shortcut key can be programmed to perform the Save Screen or Save Movie function. See
Configure Shortcut Key‚ on page 123 for details.
5VQTKPI5%/
0QVG5CXKPINCTIGHKNGUOC[VCMGUGXGTCNOKPWVGU
