SolarEdge SE3000US

Setting Up Communication
SolarEdge Installation Guide – MAN-01-00002-1.6
74
• Insert the ends of wires 1, 2, 3 and 6 into the connectors shown above.
• Insert the aluminum shield of the wire into the S connector.
• Close the screws of the Ethernet block terminal.
• Reinsert the Ethernet block terminal into the inverter card. The Ethernet
block terminal can only be inserted with the screws facing the wall
(towards the inverter heat-sink.
NOTE
:

Make sure to push in the Ethernet block terminal firmly so that it is inserted
as far in as it goes.
6 Connect the other end of the Ethernet cable to the Ethernet plug of the
Ethernet hub or router. You can connect more than one inverter to the same
hub or to different hubs, as required. Each inverter sends its monitored data
independently to the SolarEdge Monitoring server. All connections are
initiated from the inverter so that no port forwarding is required.
7 Close the inverter cover, as described in the Closing the Cover section on
page 42.
8 Verify the connection, as described in the Verifying the Connection section
on page 81.
NO
TE:
If your network has a firewall, then you may need to configure it to enable the
connection to the following address:

Destination Address: prod.solaredge.com
 Port:
22222
