Inverter User Interface
SolarEdge Installation Guide – MAN-01-00002-1.6
90
Four buttons for controlling the LCD panel menus are then accessible, as
shown below:
Figure 49: LCD Panel Menu Buttons
• Esc: Goes to the beginning of the currently entered parameter or to the
previous menu.
• Up (1): Goes up one option in a menu.
• Down (2): Goes down one option in a menu.
• Enter (3): Confirms the entry or selection of a parameter.
4 Press the Enter button for at least five seconds. The following message is
displayed:
P
l
e
a
s
e
e
n
t
e
r
P
a
s
s
w
o
r
d
*
*
*
*
*
*
*
*
The inverter is now in Setup mode and all its LEDs are lit. The inverter
automatically exits Setup mode if no buttons are pressed for more than two
minutes.
Esc
Up (1)
Down (2)
Enter (3)
