Clock synchronization with

external devices — Connection examples

LIVEN as clock master

SYNC IN

Volca series PO series

A.OUT set to ON

( → P.62)

TX.CK set to ON

( → P.68)

MIDI device

MIDI IN INPUT

SRC set to

INT
